This domestic water pressure booster set is designed for the automatic water supply of homes, households or irrigation systems, using water from wells, boreholes or tanks. Thanks to the integrated self-adapting pressure switch, the pump automatically sets the start and stop pressure according to the installation. If the automatically set start pressure does not meet the installation requirements, it can be adjusted manually. It is equipped with an opening for easy filling of the pump before operation.
The system operates automatically, starting and stopping the pump according to the set pressure, providing comfort and efficiency in use.
With a power of 750 W, the booster set allows suction of water from a depth of up to 9 m and pumping up to a maximum height of 45 m, ensuring a maximum flow rate of 67 L/min. The pump body is made of corrosion-resistant materials, steel – stainless steel, providing increased durability and reliability for long-term operation.
Technical Data:
Rated power: 750 W
Maximum suction depth: 9 m
Maximum pumping height: 45 m
Maximum flow rate: 67 L/min
Maximum working pressure: 4.5 bar
Maximum temperature of pumped liquid: max 60°C
Filter: No
Protections: over/under-voltage, lack of water, water loss, thermal (with automatic reset)
Connection: 1”
Protection rating: IP44
Noise level: 77 dB(A)
Net weight: ~ 10 kg
Do not use the product for extracting hydrocarbons (fuels, oils, solvents, etc.) or other liquids.
