The Ride-On 4x4 R1200 EvoTools +Plus® mini-tractor is a robust machine, ideal for working large agricultural areas. With impressive power and 4x4 traction, it is designed to handle demanding tasks, from ploughing to soil maintenance. It is the perfect choice for farmers and owners of extensive land.
Advantages:
- Tines pre-mounted in the box
- Faster final assembly
- LED headlight with lens
- Mirrors
- ROPS
- Seat belt
- Horn
Technical data:
Engine: Diesel Koop, 456 cmc, single-cylinder, 4-stroke, air-cooled.
Maximum power: 12 CP (12CP/3600 rpm).
Starting system: Manual and electric.
Gearbox with 3 forward gears and 1 reverse gear.
Side power take-off
Engine oil sump volume: 1.65L: 4T oil (15W40 in summer and 10W40 in cold periods)
Transmission oil sump volume: front 3.8L, rear 1.8L (Transmission oil T90)
Average fuel consumption: 2200 g/h.
Fuel tank capacity: 5.5 L.
Fuel type: diesel
Braking system: Front - hydraulic disc, Rear - hydraulic disc.
Dimensions (L x W x H): 1180 x 770 x 1800 mm.
Net weight: 254 kg (without accessories).
Wheel size: front: 4.00-8 / rear 5.00-12
Accessories:
- 2 tillers: 32 blades, 4+0 blade holders
- 2 metal working wheels
- 4 transport wheels: front 4.00-8, rear 5.00-12
Compatible accessories:
- 682368 - Attachment Coupling System for Ride-On 4x4 R1200 EvoTools +Plus® Mini-tractor.
- 682369 - Ridger for Ride-On 4x4 R1200 EvoTools +Plus® Mini-tractor.
- 682370 - Double Ridger for Ride-On 4x4 R1200 EvoTools +Plus® Mini-tractor.
- 681505 - Metal Wheels for Power Tiller and Cultivator / D[mm]: 550
- 682357 - Coupling Sleeve for Power Tiller and Cultivator EvoTools +Plus® / D[mm]: 23; L[mm]: 200
- 682494 - EvoTools® Trailer TTS500 / T: Mini-tractor
- 682840 - EvoTools® Trailer TTS500 / T: Mini-tractor with Mesh Rack
Compatible accessories together with "682368 - Attachment Coupling System for Ride-On 4x4 R1200 EvoTools +Plus® Mini-tractor.":
- 682363 - EvoTools® Row Cultivator for Power Tiller and Cultivator / H[mm]: 650
- 682361 - EvoTools® Plough for Power Tiller and Cultivator / H[mm]: 650
- 676126 - Plough for Power Tiller and Cultivator / C: 673758/679743/679744
- 681037 - Power Tiller and Cultivator Plough Type 2.
- 682360 - EvoTools® Potato Plough for Power Tiller and Cultivator / H[mm]: 650
- 676304 - Potato Plough for Power Tiller and Cultivator / C: 673758/679743/679744
- 681038 - Power Tiller and Cultivator Potato Plough Type 2.
- 682364 - Adjustable Ridger EvoTools® for Power Tiller and Cultivator / H[mm]: 650
- 676125 - Ridger for Power Tiller and Cultivator / C: 673758/679743/679744
- 681036 - Ridger for Power Tiller and Cultivator Type 2.
