Increased power and maximum versatility for professional welding projects!
Expand your working capabilities with the EvoTools +Plus® WMI 160 welding inverter, a robust digital unit designed for high performance. This "3 in 1" machine integrates the MMA, MIG/MAG (with the option of using self-shielded FCAW - No Gas wire) and TIG Lift welding processes, providing the flexibility needed to work with a wide range of materials and thicknesses.
The WMI 160 stands out with a nominal current of 160 A, allowing the use of electrodes up to 4.0 mm. Advanced software control maintains a constant output current, while the Hot Start, Arc Force and Anti-Stick functions ensure smooth welding, reducing the risk of sticking and making arc ignition easier. The digital LED display allows fast and precise adjustment, essential for achieving high-quality joints.
Safety in use is guaranteed by the protection systems against overheating and overloading, as well as by efficient fan cooling.
Technical specifications:
- Supply voltage: 230 V ~ 50-60 Hz
- Nominal output current (MMA, MIG/MAG, TIG Lift): 160 A
- Duty cycle (MMA, MIG/MAG, TIG Lift): 60% at 160 A
- Maximum absorbed power (MIG/MAG): 6.0 kW
- Maximum absorbed power (MMA): 7.2 kW
- Maximum absorbed power (TIG Lift): 4.5 kW
- Welding wire diameter (MIG/MAG): 0.8 - 1.0 mm – flux-cored wire
- Welding electrode diameter (MMA): 1.6 - 4.0 mm
- Degree of protection: IP21S
Accessories:
- MIG/MAG welding torch EURO Torch
- TIG Lift torch
- Cable with electrode holder clamp
- Cable with earth clamp
- Wire feed rollers (for ∅0.8/1.0 mm)
- Welding mask and brush
Functions:
Welding: MMA, MIG/MAG (Gas/No Gas), Tig Lift
- Anti-Stick : Prevents the electrode from sticking during MMA welding.
- Hot Start : Ensures easy arc ignition in MMA welding.
- Arc Force : Optimizes arc stability depending on the distance from the workpiece in MMA welding.
